A relatively large motor for a 12x12mm, M2 mounting pattern. This motor is ideal for lightweight 5" builds.

Check out all our Micro Motors and our selection of iFlight gear!

Features

• High-strength 5mm Steel shaft
• Japanese NSK φ8*φ3*4 bearings
• N52H curved magnets
• Motor wires protected
• Dynamically balanced

Specifications

• KV: 2300KV
• Input Voltage: 4S/6S Lipo
• Configuration: 12N14P
• Stator Diameter: 22mm
• Stator Length: 5mm
• Bottom Mounting pattern: 12*12mm/M2

• Weight: 25.5g with short wire

Includes

• 1x iFlight Xing 2205 2300Kv Micro Motor
